HD34 Square Truss
HD34 with excellent load capacity on free spans of 18m (59 feet) or to be used as tower elements, HD34 is using the 3mm wall thickness in the maintube which assures durability and extra strength. Designed for high frequency usage or installations, which demands higher loading.
Ideal trussing system for rental, touring and exhibition companies.
Made with the fast connection system and approved according the DIN EN 1999-1-1 & 1999-1-1/A2 (Eurocode 9).
Facts
- TüV approved
- Also available in any non-standard length and shape
- Tolerance free conical connector system
- Increased loading compared to FD34 (up to 50%)
- HD34 is also available as a Tower Truss
Technical specifications
Height
290 mm / 11.42 in
Width
290 mm / 11.42 in
Main Tube
50 x 3 mm / 1.97 x 0.12 in
Braces
20 x 2 mm / 0.79 x 0.08 in
Weight
~7,5 kg/m / ~5 lbs/ft
Pin Position
Diagonal
Material
EN AW-6082 T6
Connection
CS1 - CON
Productcodes & Description
Productcode
Length
Comments
HD34-025A
25 cm.
Adapter piece
HD34-029
29 cm.
HD34-050
50 cm.
HD34-075
75 cm.
HD34-100
100 cm.
HD34-150
150 cm.
HD34-200
200 cm.
HD34-250
250 cm.
HD34-300
300 cm.
HD34-350
350 cm.
HD34-400
400 cm.
